Shop Blue Diamond Attachments  |  SKU: 103600

Blue Diamond Mini Excavator Brush Cutter – Heavy Duty

$7,58100
Shipping calculated at checkout.
Size

Blue Diamond® Mini Excavator Brush Cutters are a natural extension of our skid steer brush cutter line.

The extremely rugged direct drive system has a large flywheel that stores energy and keeps the blades cutting even in difficult conditions.  These brush cutters use a 3-blade system with straight AR400 double edged blades. These rugged brush cutters have proven to be top performers paired with a wide range of mini excavators.

Features

  • Bidirectional operation
  • 1 year warranty
  • 3 blades
  • 1/4″ thick deck for 50″
  • 3/16″ thick deck for 36″ and 42″
  • New greaseable direct drive system


APPLICATIONS:

  • Mowing steep banks
  • Mowing around ponds
  • Cutting back brush on roadways and trails
  • Reaching over fences and guardrails
PART NUMBER MODEL WEIGHT (NO MOUNT) HOST MACHINE SIZE FLOW RANGE (GPM) CHAIN CURTAIN
103600 36" 550 lbs fits 6,000-15,000 lbs 13-28 No
103610 36" 550 lbs fits 6,000-15,000 lbs 29-36 No
103650 42" 625 lbs fits 7,300-19,000 lbs 13-24 No
103660 42" 625 lbs fits 7,300-19,000 lbs 25-31 No
103709 50" 914 lbs fits 12,000-19,000 lbs 13-22 Yes
103712 50" 914 lbs fits 12,000-19,000 lbs 23-28 Yes
103713 50" 914 lbs fits 12,000-19,000 lbs 28-33 Yes
103714 50" 1,216 lbs fits 12,000-19,000 lbs 34-41 Yes
MINI EXCAVATOR BRUSH CUTTER MANUAL
HD MINI EXCAVATOR BRUSH CUTTER SPEC SHEET
